ASCO 8210G094 K302372 Explosion Proof Solenoid Valve MP-C-080 238714 C302272 SCE210C094

Product Description:

The primary material used for the core diaphragm is NBR (nitrile butadiene rubber). However, alternatives such as FPM (fluororubber) and EPDM (ethylene propylene diene monomer) are also available depending on specific requirements. This variety allows the diaphragm to be suitable for different media and working environments. It boasts excellent sealing capabilities along with strong resistance to oil, operating effectively within a temperature range from -20℃ to +85℃.

The sealing parts consist mainly of O-rings and gaskets, most of which are fabricated from materials that match the diaphragm, like NBR. This ensures dependable static and dynamic sealing, effectively preventing any leakage of the media during operation.

To provide structural support and reset force, diaphragm support plates and springs made from stainless steel, typically grade 304, are employed. These components demonstrate high corrosion resistance and excellent fatigue strength, contributing to the durability and reliability of the device.

Components such as fixing clamps, core tube assemblies, and gaskets are used for precise positioning and secure assembly of the valve parts. Most of these auxiliary parts are constructed from stainless steel or metals with anti-corrosion coatings, ensuring stable installation and long-term durability.

The valves compatible with these components do not require a minimum operating pressure. Their applicable differential pressure range aligns with that of the SCE210 series, supporting low to medium pressure working conditions, although exact parameters depend on valve specifications.

These components are compatible with fluids that have a viscosity up to 65 cSt and can be used safely with media such as air, inert gases, water, and mineral oils. Safe operation is guaranteed as long as the media aligns with the sealing material characteristics.

After maintenance or replacement, the valve’s response time remains between 15 to 120 milliseconds, fulfilling the dynamic performance criteria established by the original valve.

Additionally, the valves support coils with an IP65 protection rating. All parts comply with relevant standards including CE and ATEX, thereby ensuring both electrical and mechanical safety during operation.

The core function of these components is to replace worn or damaged diaphragms and sealing parts. This replacement addresses issues such as internal or external valve leakage and operational sticking, fully restoring shut-off precision and on-off control accuracy.

Installation is versatile, supporting any angle, and the kit includes clear instructions for installation and maintenance. The replacement process is designed to be quick and straightforward, not requiring any highly specialized or complex tools.

The original components are engineered to have a long service life. They can endure from hundreds of thousands up to millions of operational cycles under normal conditions, which significantly reduces the frequency of maintenance interventions.

Technical Parameters:

Applications:

The ASCO Pulse Valve Diaphragm is a high-quality component designed for use in various industrial and commercial applications that require reliable and durable diaphragm solutions. As a crucial part of pulse valve systems, this diaphragm ensures optimal performance and longevity in controlling fluid and air flow. Thanks to its robust construction from premium materials such as Nitrile Rubber and VITON, it offers excellent chemical resistance against oil, acid, and solvents, making it ideal for harsh environments.

One of the primary application occasions for the ASCO Pulse Valve Diaphragm is in pump diaphragm repair kits. These kits are essential for maintaining and restoring the efficiency of diaphragm pumps used in water treatment, chemical processing, and pneumatic systems. The diaphragm’s compatibility with various fluids and its ability to withstand operating temperatures ranging from -20°C to +150°C make it a perfect choice for diverse repair and maintenance scenarios.

In industrial settings, the diaphragm kit is frequently used for timely replacement and repair of pulse valves in dust collector systems, pneumatic valves, and other automation equipment. The CE certification and IP65 protection rating ensure that the diaphragm meets international standards for safety and durability, providing peace of mind in critical applications. Whether in mining, manufacturing, or environmental control, the diaphragm’s chemical resistance and mechanical strength contribute significantly to system reliability and efficiency.

The ASCO Pulse Valve Diaphragm is also highly suitable for scenarios where quick turnaround is necessary. With a minimum order quantity of just one piece and a supply ability of 5000 pieces per month, it supports both small-scale repairs and large industrial demands. Packaging in sturdy cartons ensures safe delivery, and the product can be shipped within 1-7 workdays after payment, with flexible payment options including T/T, Western Union, and Paypal. Pricing is available upon negotiation, making it accessible for various budgets and project sizes.

Overall, the ASCO Pulse Valve Diaphragm stands out as an essential component in pump diaphragm repair kits and diaphragm kits used across numerous industries. Its superior chemical resistance, certified protection, and reliable performance make it an indispensable choice for maintaining and enhancing the functionality of pulse valve systems and diaphragm pumps in demanding operational environments.

Packing and Shipping:

Product Packaging and Shipping for Pulse Valve Diaphragm

Each Pulse Valve Diaphragm is carefully packaged to ensure it reaches you in perfect condition. The diaphragms are individually wrapped in protective plastic to prevent any damage or contamination during transit. They are then placed in sturdy, labeled boxes that provide additional cushioning and protection.

For bulk orders, the diaphragms are organized in multiple layers with separators to avoid any friction or deformation. All packaging materials used are environmentally friendly and comply with international shipping standards.

Shipping is carried out through reliable courier services, with options for standard, expedited, and freight shipping depending on the size and urgency of your order. Each shipment is tracked and insured to guarantee safe and timely delivery.

We recommend inspecting the package upon arrival to ensure all items are intact. In case of any damage or discrepancies, please contact our customer service immediately for assistance.
